1. First, make sure that your phone version is either on Android 7.0 and above or iOS 14.0 and above.

2. Download the boAt Crest application from Play Store for Android and App Store for iOS.

3. When you open the app, please allow all permissions.

4. Register with your mobile number by accepting the terms and conditions.

5. You will receive a verification code as an SMS. Enter the verification code in the app.

6. Follow the instructions on the app, and you will find the Wave Astra Neo smartwatch in the available device list.

7. Click on the WAVEASTRANEO_XXXX to pair the Wave Astra Neo Smartwatch with your phone.

8. This will complete the pairing process, after which the Wave Astra Neo smartwatch will start syncing with the app.

1. The operational distance for the Bluetooth is 7-10 m.

2. It is ideal that the phone and watch are in direct contact with each other.

3. If the Bluetooth is still disconnecting, close the app, switch off and switch on the Bluetooth, and start the app again.

4. Make sure the app is always running in the background.

1. Attach the magnetic end of the charging cable to the charging pad on the back of the watch.

2. Connect the USB-A end of the cable to a 5V/2A-rated power adapter, power bank, or computer.

3. The Wave Astra Neo display should show the charging status and percentage.

4. Note that charging via a computer USB port will be slower.

5. The charging adapter should be 5V, 2A.

6. Fully charge the smartwatch before using it for the first time.

1. To sync the data to the app, go to the app’s homepage and drag down the screen. This will start the syncing process, and data will be synced to the app.

2. Make sure you are in Bluetooth range and that your watch and app are nearby when you are syncing the data.

3. If the app is taking too long to sync or it gets stuck while syncing, unbind the device from the app and reconnect again.

4. If you continue to have data sync issues, please restart your phone and try again.

1. Make sure call alert and message alert are enabled from the app.

2. Sync the watch after enabling these features.

3. Even if the notifications are not coming, switch off your phone’s Bluetooth and again switch on OR restart your phone.

4. Try uninstalling and installing the boAt Crest and then start the binding process with the watch and check whether the issue is persisting or not.

5. Reset the watch and check whether the function is working or not.

Open the music player on your phone, select a song which you want to play, and control from music (play/pause/next/previous/volume up down)

Note 1: Make sure you enable music control from the app first.

Note 2: Make sure the watch is connected with the app.

1. We have designed the watch so that the display is active on a slight flick of the wrist.

2. The tracker may take a second or two to light up the screen.

3. Check if the device was not subject to any mishandling, broken wires or exposed to direct sunlight or hazards like fire and liquid.

1. Short press the side button to reach the menu.

2. Go to sleep then view sleep record.

3. To see the detailed sleep pattern, sync your watch with the app.

1. Check if the user has hair, a tattoo, skin complexion, or scarring, as this might affect the readings.

2. Wearing the watch too loosely or too tightly might also affect the readings.

3. Check if the heart rate sensor (on the bottom of the watch) is glowing green; if working properly, it should glow green.

4. Check if the device was not subject to any mishandling, broken wires, or exposed to hazards like fire and liquid.

1. SpO2 and heart rate monitoring are only for reference.

2. Data may not match with the medical equipment.

3. This watch is not medical equipment.

1. Your watch is tracking the movement of your wrist.

2. If you are doing something that requires a lot of hand movement, then the step count can be affected.

• To access watch faces from the app, users should log in to the app first.

• Short Press the side button to enter the main menu.

1. Swipe left or right on the home page would lead to shortcut menu

2. There are five functions in the shortcut menu- (i) Steps (ii) SpO2 (iii) Heart Rate Monitor (iv) Sleep (v) Music (vi) Notifications

1. Go to Settings > System > Factory Reset.

2. Alternatively, on the home screen, Swipe down > Settings icon > System > Factory Reset.

• Method 1: Using the Power Button

1. Rotate the upper side button to scroll through the default watch faces.

2. Stop on the one you want to apply, and it will be set automatically.

• Method 2: Long Press on the Home Screen

1. Long-press the home screen for a few seconds.

2. Swipe to browse available watch faces.

3. Tap the one you want to set as default.

• Short Press the side button to enter the main menu.

• Tapping the icons inside the menu will lead to different modes/options, including:

1. Steps: For tracking daily activities.

2. Heart Rate: For measuring heart rate.

3. Blood Oxygen: For measuring SpO2 level.

4. Sleep Mode: For measuring sleep hours.

5. Breathing Mode: For breathing exercise.

6. Alarm: To set up an alarm.

7. Music Control Mode: To control music.

8. Camera Control Mode: To control the camera and click photos.

9. Timer: To set up a timer.

10. Settings: To enter the watch settings.

1. There are multiple activities available such as walking, running, yoga, etc.

2. Select any one of the exercises before starting that exercise.

3. You can also add more sports activities.

4. Swipe right and then click on pause to start/pause that exercise

1. On the app home dashboard, tap on the Heart rate icon to view historical readings.

2. You can view min. and max heart rate for the day and filter history details daily, weekly, or monthly.

1. You can measure it on the watch. A user can view the details on the app

2. Swipe left from the watch home screen >> Go to SPO2>> Tap measure.

3. Post your measurement, Please sync the SPO2 values to your boAt Crest app

4. The user can view the details on the app.

1. Open the ‘boAt Crest’ app and you will find “More” on the lower right-hand side on the home page of the app.

2. Click on it and go to Settings

3. Inside Setting, you will find the Sleep Goal. You can set your Sleep Goal under this option. Please note:- Your sleep goal is indicative of your sleep target, and the watch automatically records the sleep.

• Method 1: Using the Power Button

1. Rotate the upper side button to scroll through the default watch faces.

2. Stop on the one you want to apply to—it will be set automatically.

​

• Method 2: Long Press on the Home Screen

1. Long-press the home screen for a few seconds.

2. Swipe to browse available watch faces.

3. Tap the one you want to set as default.

1. Inside the menu, click on the ‘Music Control’ icon on the watch to enter the music control feature.

2. While listening to music, users can play, pause, move back to the previous track, jump forward to the next track and control the volume of the music.

Note: This feature might not work for some of the music apps with different control protocols.

1. Inside the menu, click on the ‘Camera Control’ icon on the watch to access the remote camera.

2. Click again on the camera icon to open the camera app on the media device.

• You can control the brightness level of the watch by swiping down from the watch home screen & changing the brightness level.

• Swipe up on the home page, and you can check the cricket live scores.

You can add only 1 emergency contact through the boAt Crest app.

Follow these steps to activate the SOS feature:

1. Open the boAt Crest app on your device.

2. Navigate to the "Home Dashboard."

3. Locate the "Top Features" section on the dashboard.

4. In the "Top Features," you will find the "SOS" feature. Click on it to access the SOS functionality.

• Long-press the side button of your smartwatch to make an SOS call.

1. Go to “Settings” from the main menu and click on the “Watch Features”.

2. Tap on “Turn-by-Turn Navigation”.

3. Grant permissions for “Location”, disable “App Pause”, and enable “Background Activity”.

4. In the search bar, search for the place you wish to navigate to.

5. Tap on “Get Directions”.

6. Tap on “Preview” to check the route before starting navigation.

7. To begin turn-by-turn navigation on your watch, tap on “Navigate on Watch”.

8. Check your watch for turn-by-turn navigation alerts.

9. You can access the last alert from the watch navigation menu or by swiping left from the home screen.

10. You can also save your frequently visited places, like Home, Work, or custom locations, in your saved locations for quicker access.

1. This feature allows users to monitor and rate the quality of breathing.

2. Users can use it on the watch to do breathing exercises with a selected duration and rhythm (Inhale/Exhale pattern).

• Yes, Wave Astra Neo does have a camera feature.

• There are multiple activity modes on the watch.

• Yes, users can set individual goals for every sports mode.

1. Yes, step counting, heart rate monitoring, calorie counting and sports modes can be recorded directly on your watch while your phone is not connected.

2. The watch has some internal memory to record this data.

3. Once you are in contact with your phone, you can sync the data to the app.

1. The green lights are used to monitor your heart rate. There is an optical sensor that detects the passage of the blood and then estimates the heart rate based on that information.

2. Red light is the blood oxygen sensor.

• Yes, it can be changed.

• Yes, users can replace the strap.

• The water resistance level of the Wave Astra Neo smartwatch is IP68.
