Airdopes 141 Gen 2
The boAt Airdopes 141 Gen 2 come with boAt Signature Sound and are rated IPX4 for water and sweat resistance. They offer a total of up to 48 hours of playtime and support ASAP™ Charge, providing 180 minutes of playback in just 10 minutes. The earbuds also feature Quad Mics with ENx™ Technology for clear calls and a low latency BEAST™ Mode for gaming.
Walkthrough Video
Learn how to use the product and troubleshoot yourself
DISCOVER HOW →
Specifications
Type of Product | TWS Earbuds |
Bluetooth Version | V5.4 |
Water Resistance | IPX4 |
Music Playtime | Up to 48 hrs |
Transmission Range | 10 meters |
Driver Size | 10 mm*2 |
Frequency | 20 Hz-20 kHz |
Battery Earbuds | 40 mAh*2 |
Battery Charging Case | 450 mAh |
Charging Time | 30 mins (Earbuds); Up to 2.5 hrs (Charging Case) |
Charging Interface | USB Type-C |
Environmental Noise Cancellation (ENx™) Equipped Mics | 4 |
Low Latency | 65 ms |
User Manual
AD 141 Gen 2 User Manual.pdf
0.03 MB
Troubleshooting FAQs
General FAQs
Smart Power On - To automatically switch the earbuds on (Smart Power On), simply open the lid of the charging case when earbuds are kept inside.
Manual Power On - To manually switch the earbuds on (Manual Power On), long touch the Capacitive Touch Control (CTC) for 3 seconds on both right and left earbuds.
Smart Power Off - For Smart Power Off, after usage, place the earbuds back into the charging case and close the case lid. The earbuds will automatically switch off (and enter charging mode).
Manual Power Off - To manually power them off, long touch the CTC on both earbuds for 5 seconds (one at a time) to manually switch off the earbuds. Red LED is on for 2 seconds followed by a voice prompt to indicate the same.
NOTE: Before performing a reset, clear "Airdopes 141 Gen 2" from pairing device history by forgetting the device.
Open the lid of the charging case and place the earbuds within the case.
Long press the reset button on the charging case for 5 seconds. All four LEDs blink (3+2) 5 times on the case. Red LED blinks 5 times on the earbuds.
Close the case lid and wait for 5 seconds.
Take out the earbuds from the charging case and perform a fresh connection.
Single tap the CTC on either earbud to answer an incoming call.
Double tap the CTC on either earbud to end an ongoing call or reject incoming calls.
While playing music, single tap on the left or right earbud CTC to pause or play the track.
While playing music, double tap on the left earbud’s CTC to return to the previous track.
While playing music, double tap on the right earbud’s CTC to skip to the next track.
Volume can only be adjusted via phone/media devices.
Please note that both the earbuds can be used in Mono mode. Use either of the two options: Smart Power On or Manual Power On for switching on the desired earbud.
The selected earbud will automatically enter the connection mode indicated by alternate red and blue LED flashes.
Turn on Bluetooth on your phone/media device and search for “Airdopes 141 Gen 2” to connect.
Switch the earbuds on; both the earbuds automatically enter Connection Mode.
Turn on the Bluetooth functionality on your phone/media device and scan.
Search for ‘Airdopes 141 Gen 2’ and tap on the same for pairing & connecting via Bluetooth.
To switch to Stereo mode from Mono, simply take out the other earbud from the case. It will automatically power on and pair with the previously selected earbud, hence enabling Stereo usage.
Long touch the left earbud CTC for 3 seconds to activate ‘Google Assistant’ for Android devices and ‘Siri’ for iOS devices.
Case LED Indications (Non-Charging State):
100%: 4 LEDs show.
75%: 3 LEDs show.
50%: 2 LEDs show.
25%: 1 LED shows.
10-15%: 1 LED fast flashes.
Case LED Indications (Charging State):
0-25%: 1st LED is flashing.
25-50%: 1st LED is solid on, 2nd LED is flashing.
50-75%: 2 LEDs are solid on, 3rd LED is flashing.
75-100%: 3 LEDs are solid on, 4th LED is flashing.
Case LED indication when Earbuds are charging from the case:
If single/both earbuds are charging inside the case, the red LED remains solid on.
When both the earbuds are fully charged, the blue LED remains solid on for 30 seconds and then turns off.
Earbuds LED Indications:
Low battery (<20%): Red light quickly blinks 3 times every 30 seconds on opening the lid.
Power ON: Solid blue light flashes for 2 seconds on opening the lid.
Power OFF: Solid red LED flashes for 2 seconds when powered off.
Pairing mode: Alternate red and blue LED flashes on the master earbud, and the slave earbud LED flashes blue once every 5 seconds.
Pairing successfully (1 time indication): Solid blue LED flashes for 3 seconds.
If pairing is not successful (In pairing mode): The earbuds will show a solid red light once and auto power off.
Connected: Solid blue light flashes once every 20 seconds on both the earbuds. No LED flash when the media is playing.
Disconnected: Same as Pairing mode.
Earbuds Charging: Red LED remains solid on opening the lid.
Fully charged: Blue LED remains solid on for 30 seconds and then turns off.
Playing music: All lights are OFF (But "Connected" status will remain).
Factory Reset LED Indications:
After a successful factory reset, all four LEDs blink (3+2) 5 times on the case and red LED blinks 5 times on the earbuds.
Our IWP™ technology allows the earbuds to connect to your phone if they have already been paired before instantaneously upon opening the case.
Simply open the case and ensure that the Bluetooth is turned on for your media device, the buds will connect as soon as the case is opened without the need to take them out of the case first!
There is no special process to enable IWP™- simply follow the steps to first pair your Airdopes 141 Gen 2 to your media device. Then upon subsequent usage, the IWP™ tech will be enabled and the earbuds will pair automatically to your previously paired media device if Bluetooth is turned on in your media device.
Yes, Airdopes 141 Gen 2 is integrated with 2 mics per earbud.
Yes, it does.
Airdopes 141 Gen 2 does support 65 ms low latency for entertainment and casual gaming. However, if you’re looking for professional gaming equipment, then Airdopes 141 Gen 2 is not the right product.
No, it does not.
No, it does not.
No, the earbuds do not have any integrated volume controls on them. The volume must be controlled using your connected Bluetooth device.
Yes, long touch the left earbud CTC for 3 seconds to activate ‘Google Assistant’ for Android devices and ‘Siri’ for iOS devices.
No, the voice prompts are integrated inside the earbuds and there is no provision to turn them off or lower their volume.
While your earbuds do have IPX4 water and sweat resistance, it is recommended that they are not submerged inside water directly or used for prolonged periods inside water like for swimming/showers, as it may lead to damage.
