Airdopes 141 Gen 2

• Check if restarting the device resolves the issue.

• Check if there are any obstructions between the earbuds and the device and clear them, move the device at a closer range to the earbuds and see if it still affects it.

• Resetting your airdopes usually resolves this issue.

​

To perform a reset on your Airdopes 141 Gen 2:

NOTE: Before performing reset, clear "Airdopes 141 Gen 2" from the pairing device history by forgetting the device.

1. Place the earbuds inside the case and close the lid.

2. Long press the reset button on the charging case for 5 seconds. The following LED indication happens in case of successful reset- All four LEDs blink (3+2) 5 times on the case & Red LED blinks 5 times on the earbuds.

3. Close the case lid and wait for 5 seconds.

4. Take out the earbuds from the charging case and perform a fresh connection.

   Congratulations! Your Airdopes 141 Gen 2 has been reset.

1. To charge the earbuds, put them into the charging case in their correct orientation and close the case lid.

2. The Cyan LED on the case flashes for 5 seconds to indicate the left earbud charging from the case.

3. Purple LED on the case flashes for 5 seconds to indicate the right earbud charging from the case.

4. Blue LED on the case flashes for 5 times to indicate both earbuds charging from the case.

5. Once charging is completed, blue LED flashes for 5 seconds and the charging case automatically switches off to save power.

In the App :

• Check whether the Smart Diagnostics function of the boAt Hearables app can identify any earbud battery issues.

• To charge the case, plug one end of the cable into the case and connect the other end to a computer or a wall adapter or a power bank.

1. Check to see if the wire connected to the case is not broken. Use other wires and ensure that the charger being used is not of 9V or 12V as that will damage the case.

2. To charge the case, plug one end of the provided USB Type-C cable into the case and connect the other end to a computer, power bank, wall adapter, etc.

Note: The LEDs located on the charging case indicates the battery status of the case. Flashing LED indicates charging state and 4 solid LEDs indicate full charge.

1. Check to see if the earbuds have been put inside the case in the correct orientation.

2. If single/both earbuds are charging inside the case, the red LED remains solid on.

3. Blue LED remains solid on for 30 seconds and then turns off when both earbuds have been completely charged.

1. Charging through wall adapter – Specs of the adapter: 5V, 2A

2. Charging through cable/wire – Standard cable: 35 strands @0.10mm diameter/strand

3. Any other accessory can be used for charging the earbuds if the above norms are followed.

Note : Before using the earbuds for the first time, it is recommended to fully charge the earbuds as well as the charging case. Also, keep the lid of the charging case closed while charging.

1. Go to the sound settings of your phone and set the equalizer to normal/ default/ zero/ none.

2. Perform a factory reset.

3. In case the earbuds have water droplets, use the blow dryer to dry out any water from a distance.

4. If the earbuds are clogged with ear wax, simply clear the earbuds to restore the original sound.

5. If your device still does not get fixed then perform a factory reset

1. Check to see if the device has been properly charged first. The blue LED on the earbuds remains solid on for 30 seconds and then turns off to indicate the earbuds are completely charged.

2. Check if the voltage of the charger is correct for the charging case and if the LED on the case is solid red to indicate charging.

3. Check by switching the earbuds on manually- press and hold the capacitive touch control for 3 seconds until the LED begins to flash blue.

4. Check if the device was not subjected to any mishandling, broken wires or exposed to direct sunlight or hazards like fire.

1. Check if the controls do not work while being connected to another device.

2. Check if the media player being used supports such controls and if the controls do not function on call or with other media players.

3. Check if the controls have been physically damaged or exposed to any hazards.

1. Check if restarting the device resolves the issue.

2. Try factory resetting the device

3. Ensure that the connected device is within the Bluetooth range (10m) and there is no obstruction between the airdopes and the connected device

4. If sweat or water has gone inside the microphone then try to clean it with a cotton swab dipped in mild alchohol.

1. Check if your Airdopes model has IWP™ tech integrated.

2. Make sure that you have paired the earbuds at least once before to the device you are trying to use IWP™ with.

3. Check if Bluetooth is turned on for your media device and if it has Airdopes 141 Gen 2 in the list of paired devices.

4. Try factory resetting the device.

To perform a reset on your Airdopes 141 Gen 2:

NOTE: Before performing reset, clear "Airdopes 141 Gen 2" from the pairing device history by forgetting the device.

1. Place the earbuds inside the case and close the lid.

2. Long press the reset button on the charging case for 5 seconds. The following LED indication happens in case of successful reset- All four LEDs blink (3+2) 5 times on the case & Red LED blinks 5 times on the earbuds.

3. Close the case lid and wait for 5 seconds.

4. Take out the earbuds from the charging case and perform a fresh connection.

   Congratulations! Your Airdopes 141 Gen 2 has been reset.

• Single tap the CTC (Capacitive Touch Control) on either earbud to answer an incoming call

• Double tap the CTC (Capacitive Touch Control) on either earbud to end an ongoing call or reject incoming calls

• While playing music, single tap on the left or right earbud CTC (Capacitive Touch Control) to pause or play the track

1. While playing music, double tap on the left earbud’s CTC(Capacitive Touch Control) to return to the previous track.

2. While playing music, double tap on the right earbud’s CTC (Capacitive Touch Control) to skip to the next track

• Volume can only be adjusted via phone/media devices

1. Please note that both the earbuds can be used in Mono mode. Use either of the two options: Smart Power On or Manual Power On for switching on the desired earbud.

2. The selected earbud will automatically enter the connection mode indicated by alternate red and blue LED flashes.

3. Turn on the Bluetooth on your phone/media device and search for “Airdopes 141 Gen 2” to connect.

1. Switch the earbuds on; both the earbuds automatically enter Connection Mode.

2. This is indicated with alternate red and blue LEDs flashing on the master earbud and the blue LED flashing once every 5 seconds on the slave earbud.

3. Turn on the Bluetooth functionality on your phone/media device and scan.

4. Search for ‘Airdopes 141 Gen 2’ and tap on the same for pairing & connecting via Bluetooth.

5. To switch to Stereo mode from Mono, simply take out the other earbud from the case. It will automatically power on and pair with the previously selected earbud, hence enabling Stereo usage.

6. You can only skip to the "next track" using the right earbud in Mono/Stereo mode.

7. You can only switch to the "previous track" using the left earbud in Mono/Stereo mode.

• Long touch the left earbud CTC for 3 seconds to activate ‘Google Assistant’ for Android devices and ‘Siri’ for iOS devices.

1. Low battery (<20%) : Red light quickly blinks 3 times every 30 seconds on opening the lid. The low battery tone prompts every 5 minutes.

2. Power On : Blue LED flashes for 1 second on opening the case lid

3. Power Off : Red LED flashes for 1 second

4. Pairing Mode : Alternate red and blue LED flashes on the master earbud ; Slave earbud LED flashes blue once every 5 seconds

5. Pairing successful (1 time indication) : Solid blue LED flashes for 3 seconds

6. If pairing not successful (In pairing mode) : The earbuds will show solid red light once and auto power off

7. Connected : Solid blue light flashes once every 20 seconds on both the earbuds; No LED flash when media is playing

8. Disconnected : Alternate red and blue LED flashes on the master earbud ; Slave earbud LED flashes blue once every 5 seconds

9. Earbuds Charging : Red LED remains solid on opening the lid

10. Fully Charged : Blue LED remains solid on for 30 seconds and then turns off

11. Playing Music : All lights are OFF (But "Connected" status will remain)

This is to indicate the earbuds are getting charged from the case (when case lid gets closed):

1. If single/both earbuds are charging inside the case, the red LED remains solid on.

2. When both the earbuds are fully charged, the blue LED remains solid on for 30 seconds and then turns off.

1. Our IWP™ technology allows the earbuds to connect to your phone if they have already been paired before instantaneously upon opening the case.

2. Simply open the case and ensure that the Bluetooth is turned on for your media device, the buds will connect as soon as the case is opened without the need to take them out of the case first!

• There is no special process to enable IWP™- simply follow the steps to first pair your Airdopes 141 Gen 2 to your media device. Then upon subsequent usage, the IWP™ tech will be enabled and the earbuds will pair automatically to your previously paired media device if Bluetooth is turned on in your media device.

• Yes, Airdopes 141 Gen 2 is integrated with 2 mics per earbud

• Yes

• Airdopes 141 Gen 2 does support 65 ms low latency for entertainment and casual gaming. But if you’re looking for professional gaming equipment, then Airdopes 141 Gen 2 is not the right product

• No

• No

1. No, the earbuds do not have any integrated volume controls on them. The volume has to be controlled using your connected Bluetooth device.

2. Ensure that in the Bluetooth settings of your media device, you have enabled syncing of Bluetooth and phone volume levels otherwise you may not be able to fully control the volume of the earbuds as intended.

• Yes

• No, the voice prompts are integrated inside the earbuds and there is no provision to turn them off or lower their volume.

• While your earbuds do have IPX4 water and sweat resistance, it is recommended that they are not submerged inside water directly or used for prolonged periods inside water like for swimming/showers, as it may lead to damage.
