141 Elite ANC

1. Check that both earbuds are out of the charging case.

2. They should automatically enter Connection Mode, which is indicated by alternating red and blue LED flashes.

3. If one earbud does not power on automatically, try manually turning it on by long touching the Capacitive Touch Control for 3 seconds.

4. You can also try placing the earbuds back in the charging case and then using them again to see if they reconnect.

5. Performing a factory reset may also resolve the problem.

• Resetting the device usually resolves such issues.

• Before performing a reset, clear "Airdopes 141 Elite ANC" from your device's pairing history.

• To perform a reset:

1. Place the earbuds within the case in the correct orientation and keep the case lid open.

2. Press and hold the reset button on the charging case for 10 seconds. The earbuds' red LED will rapidly blink 5 times, and the charging case's white LED will rapidly blink 5 times after a successful reset.

3. Close the case lid and wait for 5 seconds.

4. Open the case lid, take out the earbuds, and perform a fresh connection.

5. If the issue is not resolved, try manually powering the earbud off and on again.

6. You can also perform a factory reset through the app by going to the Troubleshooting section, tapping "Malfunctioning," and selecting "Reset My Device". The earbuds will then show as "Ready to Pair" in the "My Devices" section.

1. The boAt Hearables app displays all currently and previously paired devices in the ‘My Devices’ section.

2. Once your earbuds are paired with your smartphone, the status will change to “Connected” on the thumbnail.

3. Tap the thumbnail to check if both the left and right earbuds are connected and to view their battery levels.

If IWP™ isn't functioning:

1. Confirm that your Airdopes model has IWP™ tech integrated.

2. Make sure you have paired the earbuds at least once before to the device you are trying to use IWP™ with.

3. Check if Bluetooth is turned on for your media device and your product name is in the list of paired devices.

4. Try factory-resetting the device.

1. To charge the earbuds, put them into the charging case in their correct orientation.

2. While charging, a white LED on the case remains solid ON for 5 seconds.

3. Once the charging is complete, the charging case automatically switches off to save power and the LED indicator turns off.

1. To charge the case, plug one end of the provided USB Type-C cable into the case and the other end into a computer, power bank, or wall adapter.

2. A continuously flashing white LED indicates that the case is charging, and a solid white LED means it is fully charged.

1. Check that the cable connected to the case is not broken.

2. Use a different cable and ensure the charger is not 9V or 12V, as this can damage the case.

3. The white LED on the case flashes continuously to indicate that it is charging.

1. Check that the earbuds have been placed in the correct orientation inside the case.

2. A white LED on the case will remain on for 5 seconds to show that the earbuds are charging. This light will turn off when they are fully charged.

3. You can run the Smart Diagnostics function in the boAt Hearables app to check for firmware-related battery issues, but it cannot identify hardware problems

1. Charging through wall adapter – Specs of the adapter: 5V, 2A

2. Charging through cable/wire – Standard cable: 35 strands @0.10mm diameter/strand

3. Any other accessory can be used for charging the earbuds if the above norms are followed.

Note : Before using the earbuds for the first time, it is recommended to fully charge the earbuds as well as the charging case. Also, keep the lid of the charging case closed while charging.

1. Go to your phone's sound settings and set the equalizer to normal/default/none/0.

2. If the earbuds are clogged with earwax, clean them to restore the sound.

3. If there are water droplets, use a blow dryer from a distance to dry them out, being careful not to overheat the product.

4. You can also run the Smart Diagnostics function in the boAt Hearables app to check for speaker-related issues but note that it can only identify firmware-related problems.

1. Ensure the charging case has a charge.

2. Try to manually power on the earbuds by long touching the Capacitive Touch Control for 3 seconds. Powering on is indicated by a solid blue LED for 1 second.

3. If they still don't power on, try cleaning the pogo pins (magnetic charging pins) of the earbuds with a cotton swab dipped in alcohol or spirit.

4. After cleaning, wipe the pins with a dry cotton swab to prevent moisture from remaining.

5. Place the earbuds back in the charging case, close the lid, and then open it again after 5 seconds. The earbuds will automatically power on and their LEDs will start blinking.

1. To troubleshoot control issues: Check if the controls work when connected to a different device.

2. Verify that the media player you're using supports such controls and check if they function on a call or with other media players.

3. Check if the controls have been physically damaged or exposed to any hazards.

1. Try restarting the device.

2. Perform a factory reset.

3. Make sure there are no objects between your earbuds and the connected device.

4. Move your device closer to the earbuds to see if the connection improves.

5. Look closely at the microphone hole for dirt or earwax. If it seems blocked, gently clean the area.

6. You can also run the Smart Diagnostics function in the boAt Hearables app to check for mic issues. Note that it can only identify firmware problems, not hardware.

Note: Before performing a factory reset, clear "Airdopes 141 Elite ANC" from your device's pairing history by forgetting the device.

1. Place the earbuds inside the case with the lid open. Press and hold the reset button on the charging case for 10 seconds. Red LEDs on the earbuds and a white LED on the charging case will rapidly blink 5 times after a successful reset.

2. Close the case lid and wait for 5 seconds.

3. Open the lid, take the earbuds out, and perform a fresh connection.

• Single tap the Capacitive Touch Controls (CTC) on either earbud to answer an incoming call.

• Double tap the Capacitive Touch Controls (CTC) on either earbud to end an ongoing call or reject incoming calls.

• While playing music, single tap on the left or right earbud Capacitive Touch Controls (CTC) to pause or play the track.

1. While playing music, double tap on the left earbud’s Capacitive Touch Controls (CTC) to return to the previous track.

2. While playing music, double tap on the right earbud’s Capacitive Touch Controls (CTC) to skip to the next track.

• Volume can only be adjusted via phone/media devices.

1. To use a single earbud in mono mode, you can use either the Smart Power On or Manual Power On methods.

2. The selected earbud will automatically enter connection mode, indicated by red and blue LED flashes.

3. Turn on Bluetooth on your device and search for “Airdopes 141 Elite ANC” to connect.

1. To use both earbuds in stereo mode, switch them on. They will automatically enter Connection Mode.

2. Turn on Bluetooth on your device, search for “Airdopes 141 Elite ANC,” and tap to pair.

3. To switch from mono to stereo mode, simply take the other earbud out of the case; it will automatically power on and pair with the first earbud.

• The voice assistant cannot be activated using Airdopes 141 Elite ANC.

1. Earbuds Low Battery (<30%): The red-light blinks 3 times when the case lid is opened.

2. Earbuds 30-100% Charged: The blue light blinks 3 times when the case lid is opened.

3. Power ON: The blue light is ON for 1 second upon opening the lid.

4. Power OFF: The red LED is ON for 1 second when manually powered off.

5. Pairing Mode: Red and blue LEDs blink alternately on the master earbud, while the slave earbud blinks blue every 5 seconds.

6. Connected: The blue light flashes on and off alternately 3 times each minute, but there is no LED flash when media is playing.

7. Disconnected: The same as pairing mode; red and blue LEDs blink alternately on both earbuds, and the slave earbud blinks blue every 5 seconds.

8. Earbuds Charging from Case: The case's white LED stays steady for 5 seconds when the lid is closed.

9. Earbuds Fully Charged: The case's LED turns off when the lid is closed.

10. Case Battery Status (<30%): The white LED blinks quickly for 3 seconds when the lid is opened or closed.

11. Case Battery Status (30-70%): The white LED normally blinks 3 times when the lid is opened or closed.

12. Case On Charging: The white LED flashes continuously.

13. Case Fully Charged (100%): A solid white LED is displayed.

14. Factory Reset Successful: The red LED on the earbuds and the white LED on the charging case quickly blink 5 times.

1. Our IWP™ technology allows the earbuds to connect to your phone if they have already been paired before instantaneously upon opening the case.

2. Simply open the case and ensure that the Bluetooth is turned on for your media device, the buds will connect as soon as the case is opened without the need to take them out of the case first!

• There is no special process to enable IWP™- simply follow the steps to first pair your Airdopes 141 Elite ANC to your media device. Then upon subsequent usage, the IWP™ tech will be enabled and the earbuds will pair automatically to your previously paired media device if Bluetooth is turned on in your media device.

• Yes, Airdopes 141 Elite ANC is integrated with 2 mics per earbud.

• Yes, it does.

• Airdopes 141 Elite ANC does support 50 ms low latency for entertainment and casual gaming. However, if you’re looking for professional gaming equipment, then Airdopes 141 Elite ANC is not the right product.

• No, it does not.

• No, it does not.

• No, the earbuds do not have any integrated volume controls on them. The volume must be controlled using your connected Bluetooth device.

• The voice assistant cannot be activated using Airdopes 141 Elite ANC.

• No, the voice prompts are integrated inside the earbuds and there is no provision to turn them off or lower their volume.

To install the boAt Hearables app, you can follow one of the options mentioned below-

1. Scan QR Code: Airdopes 141 Elite ANC has the Hearables app QR code printed on the packaging box. Simply scan this code using your smartphone. The subsequent link will redirect you to the Google Play Store and iOS Store, and you can select the applicable option.

2. Google Playstore: Download the boAt Hearables app from the Google Play Store on your Android smartphone.

3. App Store: Download the boAt Hearables app from the App Store on your iOS smartphone.

1. After installing the app, follow the steps shown to set up your account by entering your phone number, name, and email ID.

2. Account setup is a one-time action.

1. Turn on Bluetooth on your phone and log in to your account on the Hearables app.

2. Go to the "My Devices" section, open the case lid, and the Airdopes will show up with a "Ready to Pair" status.

3. Tap the Airdopes name and accept the pairing request.

• To reset your Airdopes from the app, go to the Troubleshooting section, tap "Malfunctioning," and click on "Reset My Device".

1. You can toggle between ANC OFF/Ambient/ANC ON modes by long touching the right earbud's Capacitive Touch Control for 3 seconds.

2. By default, ANC Off (Normal) mode is active.

1. You can switch between boAt Signature Sound and Balanced Mode by long touching the left earbud's Capacitive Touch Control for 3 seconds.

2. By default, boAt Signature Sound mode is active.

• Under the Sound tab, you can tap and listen to music on JioSaavn or Kuku FM.

1. You can use the System tab to learn about how you can choose the correct ear tip sizes.

2. Additionally, you can access the user manual for Airdopes 141 Elite ANC under this tab.

1. The earbuds have IPX5 water and sweat resistance.

2. However, it is not recommended to submerge them in water or use them for prolonged periods during activities like swimming or showering, as this may cause damage.
